Leading Trustworthy Top Quality Most Professional
COB LED Strip Manufacturer Since 2005

Unitop is one of the best COB LED strip manufacturers, with over 17 years of manufacturing and OEM experience. We have confidence in our LED strips. Our prices will be much lower than other competitors for the same quality products. Because We have suitable LED strips raw material partners. We have the confidence and ability to make you more money and create a better reputation.
We have always maintained the spirit of innovation. We constantly develop new products or innovate based on present products every year. We also accept OEM or ODM according to customers’ special requirements.

About Unitop Get Free Quote

Features & Benefits

You can find below the significant features & benefits of COB LED strips that we manufacture, by this way, you will feel more confident in us.

What is COB LED Strip?

The new Unitop flexible COB LED Strips are strikingly consistent in color and brightness. Their unique COB technology enables hundreds of LED chips to be encapsulated in the tiniest flexible circuit board. Combined with a phosphor layer on the LED Strip, it generates a continuous, uniformly bright light line along the entire length. There are no noticeable light spots compared with typical standard SMD LED strips. In our factory, COB LED strip is also called COB flexible LED Strip or FCOB LED Strip. Despite the single white color, we also have RGB COB LED strip. Just contact us immediately to get the latest prices.

COB LED Strip VS Traditional LED Strip

COLOR MANAGEMENT

Minimum yellow spots, higher color saturation, and a comprehensive range of CCT options with the best color consistency. You will feel more natural and comfortable under such a humanistic lighting environment.

Product Range

CIRCUIT BOARD & CHIPS

Highest quality flexible PCB, big chips, low voltage, large voltage drop margin, No light difference from the beginning to the end. This ensures better brightness and performance when the light is on.

Product Display

PRODUCT MANAGEMENT

Full range of strip LED COB including cost-effective solution, project solution, high-density solution, high brightness solution, etc. This way, we can be your COB LED strip light one-stop provider.

Product Range

PRODUCTION TESTING

Fully automatic soldering, thermal shock test, high temperature, and humidity test, twist test, etc. CE/RoHs, cUL, LM-80. 3-year warranty. Then you do not have to worry about the quality of our products.

Product Display

Wholesale COB LED Strips By Series

You can click on Model No. in the below sheet to go to each product’s page to view more. We are one of China’s best COB LED strip manufacturers, suppliers, and factories. We offer a full range of COB LED strips as below:

Product SeriesModel No.LED QtyColorCRIAnglePCB WidthVoltageWattageLumenIP OptionsSpec. & Reports
Basic SeriesUTFS-BSCOB320-2408320pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°8mmDC24V4.5W/M94.9lm/W 427.1lm/MIP20
IP65
IP66		Download
Basic SeriesUTFS-BSCOB320-2410320pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°10mmDC24V8W/M92.8lm/W 742.4lm/MIP20
IP65
IP66		Download
Popular SeriesUTFS-PSCOB420-2408420pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°8mmDC24V10W/M86lm/W
860lm/M		IP20
IP65
IP66
IP67		Download
Popular SeriesUTFS-PSCOB420-2410420pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°10mmDC24V12W/M86.4m/W
1036.8lm		IP20
IP65
IP66
IP67		Download
High Efficiency SeriesUTFS-HECOB480-2408480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°8mmDC24V8W/M92.4Lm/W
739lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency SeriesUTFS-HECOB480-2410480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°10mmDC24V12W/M95.1Lm/W
1141lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency RedUTFS-HECOB480-2408R480pcs/M620-630nmn/a180°8mmDC24V8W/M7.25Lm/W
58lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency GreenUTFS-HECOB480-2408G480pcs/M520-530nmn/a180°8mmDC24V8W/M122Lm/W
976lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency BlueUTFS-HECOB480-2408B480pcs/M455-465nmn/a180°8mmDC24V8W/M18.8Lm/W
150.4lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency RedUTFS-HECOB480-2410R480pcs/M620-630nmn/a180°10mmDC24V12W/M8.9Lm/W
107lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency GreenUTFS-HECOB480-2410G480pcs/M520-530nmn/a180°10mmDC24V12W/M122.55Lm/W
1470lm/M		IP20
IP65
IP66
IP67		Download
High Efficiency BlueUTFS-HECOB480-2410B480pcs/M455-465nmn/a180°10mmDC24V12W/M20.3Lm/W
243.5lm/M		IP20
IP65
IP66
IP67		Download
High Wattage SeriesUTFS-HWCOB480-2408480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°8mmDC24V12W/M84lm/W 1008lm/MIP20
IP65
IP66
IP67		Download
High Wattage SeriesUTFS-HWCOB480-2410480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°10mmDC24V16W/M94lm/W 1504lm/MIP20Download
Ultra Thin SeriesUTFS-UTCOB480-2404480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°4mmDC24V4W/M100.2lm/W 401lm/MIP20Download
Ultra Thin SeriesUTFS-UTCOB480-2406480pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°6mmDC24V6W/M98.2lm/W 589lm/MIP20Download
RGB SeriesUTFS-COB840-2410RGB840pcs/M620-630nm, 520-530nm, 460-470nmn/a180°10mmDC24V15W/M43.5lm/W 652.5lm/MIP20
IP65
IP66		Download
RGBW SeriesUTFS-COB560-2412RGBW560pcs/M620-630nm,
520-530nm,
460-470nm,
2700K / 3000K / 4000K / 6500K		n/a180°12mmDC24V16W/M40.7lm/W 651.2lm/MIP20 Download
Tunable White SeriesUTFS-TWCOB840-2410840pcs/M3000K, 6500K≥90Ra180°10mmDC24V12W/M85.8lm/W 1030lm/MIP20
IP65
IP66		Download
Constant Voltage & Current Super Long SeriesUTFS-SLCOB420-2410420pcs/M2700K, 3000K, 4000K, 6500K≥90Ra180°10mmDC24V8.64W/M100lm/W 864lm/MIP20
IP67		Download

Important! Model No. Definition:

Take Model No. UTFS-BSCOB320-2408 as an example:

“UT” stands for “Unitop”.
“FS” stands for “LED Flexible Strip”.
“BS” stands for “Basic Series”. Other options will be: “PS” stands for “Popular Series”, and so on.
“COB” stands for “This LED strip is adopting COB LEDs”.
“320” stands for “This strip is adopting 320LEDs/M”, other options will be “420, 480, 840” stands for “420LEDs, 480LEDs or 840LEDs/M individually”.
“24” stands for “This LED strip is 24V COB LED strip light”. If it is “12” it will mean “12V COB LED strip”
“08” stands for “The LED strip PCB width is 8mm”, other options will be “4, 6, 10, 12” each stands for “4mm, 6mm, 10mm or 12mm PCB width”.
“R” or “RGB” or “RGBW” after above Model No. stand for different colors or else.

Product Display

You can find our complete range of COB LED strips displayed below. Just click on any one to view more in more details!

COB LED Tape Light

COB LED Strip With 320LEDs/M, 8mm Width PCB

COB LED Tape Light

COB LED Strip With 320LEDs/M, 10mm Width PCB

COB LED Flex Strip

COB LED Strip With 420LEDs/M, 8mm Width PCB

COB LED Flex Strip

COB LED Strip With 420LEDs/M, 10mm Width PCB

COB LED Strip

High Efficiency COB LED Strip With 480LEDs/M, 8mm Width PCB

COB LED Strip

High Efficiency COB LED Strip With 480LEDs/M, 10mm Width PCB

COB LED Strip 2 UTFS-HECOB480-2408R

Red COB LED Strip With 480LEDs/M, 8mm Width PCB

COB LED Strip 4 UTFS-HECOB480-2408G

Green COB LED Strip With 480LEDs/M, 8mm Width PCB

COB LED Strip 2 UTFS-HECOB480-2408B

Blue COB LED Strip With 480LEDs/M, 8mm Width PCB

COB LED Strip 2 UTFS-HECOB480-2408R

Red COB LED Strip With 480LEDs/M, 10mm Width PCB

COB LED Strip 4 UTFS-HECOB480-2408G

Green COB LED Strip With 480LEDs/M, 10mm Width PCB

COB LED Strip 2 UTFS-HECOB480-2408B

Blue COB LED Strip With 480LEDs/M, 10mm Width PCB

Load more

Product Test

You will feel happy to buy from us if you see so many strict tests done on our COB LED strips to ensure superior performance, reliability, and prolonged lifespan, without which we will never put any products into mass production.

Twist Test

Twist Test

Rotate the front and back sides 900–1200 degrees, cycling 1000 times.

Winding Tensile Test

Winding Tensile Test

3cm diameter test rod, winding and stretching.

High Frequency Vibration Test

High Frequency Vibration Test

180 vibrations per minute for 2 hours.

High Temperature Storage Test

High Temperature Storage Test

168 hours in a sealed environment at 80°C

Low Temperature Storage Test

Low Temperature Storage Test

168 hours in a sealed environment at -45°C.

High Low Temperature Shock Test

High & Low-Temperature Shock Test

Under -45°C, 80°C for 30 minutes each, 5 minutes shock test, continuously for 120 hours.

High Temperature High Humidity Test

High Temperature & High Humidity Test

Temperature 80°C, humidity 65-90RH, in a sealed environment for 168 hours.

IES Test

IES Test

We always provide IES files to our customers on demand.

Having Special Requirements?

You can’t find what you want from the above product range? Don’t worry. We warmly welcome any OEM & ODM. Please kindly help to send us your specific requirements. We will evaluate and reply to you ASAP.

  • Dimension

    Unitop offers amazing custom service, you can choose your COB LED strip with various dimensions such as PCB width, thickness and etc. Our standard length is 5M/Reel, but you can also ask us to make it longer or shorter as per your projects’ requirements. You can also choose different shapes.

  • CCT & CRI

    Unitop factory manufactures various color COB LED strips. Our standard colors offered are: White: 2700K(2670-2820K), 3000K(2980-3150K), 4000K(3860-4140K), 6000K(6250-6750K). All white LEDs are with CRI as 90Ra. If your projects require special CCT or CRI such as 95Ra or 98Ra, please feel no hesitate to let us know. We also have various color options such as Red(620-630nm), Green(520-530nm), and Blue(455-465nm), we also offer RGB, RGBW, and tunable white series.

  • Voltage & Wattage

    Unitop offers various voltage and wattage options for your requests. Our standard voltage is 24VDC, however, we can also offer 5V, 12V, 36V, and 48V COB LED strips as per your projects. We believe every project is different, some projects need high efficacy and less wattage, and some need high wattage and more brightness.

  • IP Ratings

    Normally our best seller COB strips are IP20, However, according to your projects, you can let us know which other IP ratings you need such as IP65, IP66, IP67, etc.

  • Application

    Please let us know more about your project and application details. Our professional team will offer you the best solution under your budget.

  • Quantity

    Please tell us the quantity you need. We usually do not have MOQ requirements, while more quantity helps you to get lower prices on the COB strips.

  • Warranty Period

    Please let us know your warranty requirements. We usually will offer a 3-year warranty for our standard COB LED strips. Different warranty periods will involve different solutions for raw materials and others.

  • Your Own Logo

    Not only we can print your own brands/logos on the COB LED strips, but also we can put them on the outside cartons. In this way, your customers will see that you are more professional and surely they will buy more products from you. We hope to achieve win-win cooperation with you.

  • Anything else

    Despite the above, if you need to achieve some different functions or features on the COB LED strips? Or anything else? Please feel free to let us know.

Send Specific Requirements

Applications

There are many applications, including(but not limited to) the following. This way, you will have more ideas about how and where to use our COB LED strips.

COB LED strips in Home Ceiling Lighting

COB LED strips in Home Ceiling Lighting

COB LED strips in Shopping Mall

COB LED strips as Supermarket Lighting

COB LED strips in Aisle Contour Lighting

COB LED strips in Bedroom Atmosphere Lighting

COB LED strips in Hallway Decoration Lighting

COB LED strips in Stairs Lighting

COB LED strips in Stairway Lighting

COB LED strips in Office Lighting

COB LED strips Under Cabinet Lighting

COB LED strips in Hotel Lighting

COB LED strips in Hotel Lighting

COB LED strips in KTV as Decoration Lighting

COB LED strips in Night Club as Decoration Lighting

COB LED strips in Car Decoration Lighting

Helpful Articles for Choosing LED Strips

Do you have difficulty how to choose LED strips? Or do you want to know more technical details, product knowledge, reviews or comparisons, or more? Just read below helpful articles.

What are the Advantages of COB LED Flexible Strip?

2022年1月16日/by Tom Woo

How To Choose LED Power Supply

2022年1月12日/by Tom Woo

Top 9 considerations before buying LED strip lights

2022年1月5日/by Tom Woo

Creative Ways to Use LED Strip Lights in your Home

2021年12月31日/by Tom Woo

13 Precautions For Installation of LED Strip Light

2021年12月30日/by Tom Woo

Rope Light vs LED Flexible Strip: What are the differences?

2021年12月29日/by Tom Woo

5 Reasons to Add Attractive Cove Lighting

2021年12月27日/by Tom Woo

LED Strip Light Buying guide: How to select LED strip Lights

2021年12月22日/by Tom Woo

Frequently Asked Questions

Do you want to see what kind of questions people always ask? Or do you want to find some replies to your questions? Suggest you don’t miss this part.

Our Basic Series COB strips are with 320chips/M, this series are the most cost-effective version, if you are looking for lowest prices, this can be a good choice for you.

Our Popular Series COB strips are with 420chips/M, this series are our best seller series. The design and prices are coming to a balance point.

Our High Efficiency Series COB strips are with 480chips/M, if you want lowest wattage while maximum lumens, this can be the best solution.

Our High Wattage Series COB strips are also with 480chips/M, if you want the maximum lumens without considering the power consumption. This can be the most suitable solution.

COB Strips comparison

Chip on board (COB) is a method of circuit board manufacturing in which the integrated circuits (e.g. microprocessors) are attached (wired, bonded directly) to a printed circuit board, and covered by a blob of epoxy. By eliminating the packaging of individual semiconductor devices, the completed product can be more compact, lighter, and less costly. In some cases, COB construction improves the operation of radio frequency systems by reducing the inductance and capacitance of integrated circuit leads. For more details of this technology, you can check Wikipedia.

what is COB

COB is also a type of LED, so this question does not make any sense. However COB LEDs have many advantages comparing with traditional SMD LEDs, you can continue read our FAQ as below.

The CRI of the COB LEDs which we are using are all more than 90Ra. Thus we also call our COB LED strip as High CRI COB LED strip. Generally speaking, CRI(colour rendering index) values 90 and above are considered to be excellent, however values below 80 are generally considered not good. CRI comparison

There are a lot of advantages of COB LED strips including no lighting spots, better light, more flexible, more efficient, and etc. You can read our article for this.

COB LED technology produces a considerably brighter light than traditional LED technology! They’re even more bright than high-density strips. Flip-chip LEDs, unlike SMD LEDs, are not enclosed in a plastic holder, therefore they produce dazzling, constant light from a broader angle. This enables them to generate light from the strip’s sides, which reaches more than 180 degrees. A wider light angle gives you more light, which is important for long-term brightness.

Yes, they are dimmable.

Our standard COB LED strip light is IP20, we also have IP65, IP66, IP67, IP68 for choice. See below:

10. Waterproof

UTFS-SLCOB420-2410-IP67

Our standard COB LED strips packages are:

  1. Normally one reel COB LED strip is 5m, we have also other lengths for different series;
  2. One reel COB LED strip is put into a ESD bag/Anti-static foil bag, also we have put a desiccant inside the bag;
  3. 25 reel of COB strips are put into one inner box carton;
  4. 4 inner boxes are put into one outerbox carton. So normally one carton will have 100reels COB strips.

package

standard package

  1. Clean the installation surface.
  2. Measure the length you need to install, cut at the nearest cutting mark. For the remaining strip, weld at the next scissor mark to connect with other connection wire.
  3. Do not pull the whole strip from the back release paper at one time. Do not hard press the LEDs.
  4. Connect strip wire to the driver output side (Positive to positive, negative to negative.)
  5. Connect the driver plug to wall socket.
  6. Switch on and enjoy.

1. Clean the surface2. Cut the strips3. Pull the back 3M tape4. Connect to driver5. Switch on

Absolutely, we offer various types aluminum profile with different sizes for our COB LED strips, the dimensions which we can offer include but not limited as below:

0809 / 1013 / 1506
1612 / 1616/ 1616B/ 1707 / 1708 / 1708B / 1715B / 1715C / 1715D / 1919 / 1919B
2020 / 2020B / 2027 / 2027B / 2727
2206 / 2212 / 2308 / 2315 / 2410 / 2416 / 2507 / 2711
3110 / 3628 / 3535 / 5635

UTAP-0809 Aluminum Profile

UTAP-1013 Aluminum Profile

UTAP-2020 Aluminum Profile

UTAP-2410 Aluminum Profile

UTAP-3535 Aluminum Profile

UTAP-5635 Aluminum Profile

Sorry we have so many aluminum profiles, and it is not easy for us to put all here one by one. If you want to know which types of aluminum to use on specific COB LED strips, you can go to individual product page to check into details. We love OEM jobs, so you can ask as to design and make any special aluminum profiles for your projects. Just contact us immediately and send us your specific requirements.

It is our goal to provide our customers best quality products. To ensure our COB LED tapes are with highest quality, we have put them all in strict tests in our own factory labs and also the Safety Agencies. All our COB LED strips are with CE, RoHS certificates. Many of our customers also used our products to get certificates in their own countries.

Unitop COB LED Strip EMC Unitop COB LED Strip RoHS LM-80
