360° LED Neon Flex D25 Black IP65 24VDC

360° LED Neon Flex Black series is a type of distinctive optical design for 360° uniform, shadow-free light emission, featuring a unique black silicone body for seamless integration into various environments.

Model No.:UTNF-360D25 Black
Dimension:Diameter 25mm
Voltaj:DC24V
Watt:5W or 10W or 16W /m
CCT:2400K, 2700K, 3000K, 3500K, 4000K, 5000K, Tunable White, Red, Green, Blue, Yellow, Pink, Orange, RGB, RGBW
CRI:≥90Ra
Angle:360°
IP Rate:IP65
UTNF-360D25 Black 360° LED Neon Flex feature

Unitop 360° Silicone LED Neon Flex Rope Light D25 Black series has so many unique features, including but not limited to below:

360° Emitting Uniformly:

Unlike traditional LED strips that emit light primarily in one direction, 360° LED Neon Flex emits light uniformly in all directions around its entire circumference. This means that it provides consistent and even illumination from all angles, leaving no dark spots or shadows.

360° LED Neon Flex emitting uniformly

Flexible and Malleable:

Our 360° LED Neon Flex, featuring a unique product structure, is engineered to be both rigid and flexible, offering exceptional malleability. This design allows for versatile application across various environments, accommodating complex shapes and surfaces while maintaining durability and aesthetic appeal.

360° LED Neon Flex structure

High CRI More Than 90Ra:

The CRI of the LEDs we are using is all more than 90Ra. Thus we also call our LED Neon Flex: High CRI LED Neon Flex. Generally speaking, CRI(color rendering index) values of 90 and above are considered excellent; however, values below 80 are generally considered not good.

CRI karşılaştırması

IP 65:

Our 360° LED Neon Flex is IP65 protected, UV resistant, solvents resistant, and saltwater resistant. Dot-free will bring the most excellent performance for indoor and outdoor applications.

360° LED Neon Flex IP65

Boyut ve Uzunluk:

Note: The length of “L” is the length of the Neon Flex, which is the integer multiple of the minimum cutting length.

UTNF-360D25 dimension

Elektrik ve Lümen Verileri:

Photoelectric parameters (5W)

Unitop Model No.RenkCCTCRIGörüş AçısıLümen
LM/M
Etkinlik LM/WÇalışma GerilimiGüçIP Oranı
UTNF-360D25 Black-5WW Sıcak Beyaz2400K≥90Ra360°377.424VDC5W/MIP65
UTNF-360D25 Black-5WW Sıcak Beyaz2700K≥90Ra360°387.624VDC5W/MIP65
UTNF-360D25 Black-5WW Sıcak Beyaz3000K≥90Ra360°40824VDC5W/MIP65
UTNF-360D25 Black-5WW Sıcak Beyaz3500K≥90Ra360°397.924VDC5W/MIP65
UTNF-360D25 Black-5NW Doğal Beyaz4000K≥90Ra360°397.924VDC5W/MIP65
UTNF-360D25 Black-5DW Daylight White5000K≥90Ra360°377.424VDC5W/MIP65
UTNF-360D25 Black-5R R: 620-630nm//360°193.824VDC5W/MIP65
UTNF-360D25 Black-5G G: 520-530nm//360°367.224VDC5W/MIP65
UTNF-360D25 Black-5B B: 465-475nm//360°4.60.924VDC5W/MIP65
UTNF-360D25 Black-5YY: 585-595nm//360°142.824VDC5W/MIP65
UTNF-360D25 Black-5PPink//360°30624VDC5W/MIP65
UTNF-360D25 Black-5TW Tunable white2700K-5000K≥90Ra360°166.524VDC5W/MIP65
UTNF-360D25 Black-5RGB RGB//360°13.42.724VDC5W/MIP65

Photoelectric parameters (10W)

Unitop Model No.RenkCCTCRIGörüş AçısıLümen
LM/M
Etkinlik LM/WÇalışma GerilimiGüçIP Oranı
UTNF-360D25 Black-10WWSıcak Beyaz2400K≥90Ra360°75724VDC10W/MIP65
UTNF-360D25 Black-10WWSıcak Beyaz2700K≥90Ra360°787.424VDC10W/MIP65
UTNF-360D25 Black-10WWSıcak Beyaz3000K≥90Ra360°837.824VDC10W/MIP65
UTNF-360D25 Black-10WWSıcak Beyaz3500K≥90Ra360°827.824VDC10W/MIP65
UTNF-360D25 Black-10NWDoğal Beyaz4000K≥90Ra360°807.724VDC10W/MIP65
UTNF-360D25 Black-10DWDaylight White5000K≥90Ra360°757.224VDC10W/MIP65
UTNF-360D25 Black-10RR: 620-630nm//360°403.824VDC10W/MIP65
UTNF-360D25 Black-10GG: 520-530nm//360°736.524VDC10W/MIP65
UTNF-360D25 Black-10BB: 465-475nm//360°121.124VDC10W/MIP65
UTNF-360D25 Black-10YY: 585-595nm//360°292.824VDC10W/MIP65
UTNF-360D25 Black-10PPink//360°625.824VDC10W/MIP65
UTNF-360D25 Black-10TWTunable white2700K-5000K≥90Ra360°336.424VDC10W/MIP65
UTNF-360D25 Black-10RGBRGB//360°24.82.524VDC10W/MIP65

Fotoelektrik parametreler (16W)

Unitop Model No.RenkCCTCRIGörüş AçısıLümen
LM/M
Etkinlik LM/WÇalışma GerilimiGüçIP Oranı
UTNF-360D25 Black-16RGBWRGB+2200K//360°24.26.124VDC16W/MIP65
UTNF-360D25 Black-16RGBWRGB+2700K//360°26.66.624VDC16W/MIP65
UTNF-360D25 Black-16RGBWRGB+3000K//360°25.96.524VDC16W/MIP65
UTNF-360D25 Black-16RGBWRGB+4000K//360°25.76.424VDC16W/MIP65
UTNF-360D25 Black-16RGBWRGB+4500K//360°25.16.324VDC16W/MIP65

Kablo girişi:

cable entry

Not:

1. Lütfen şu adrese gidin İndir Daha fazla ayrıntı için bölüm.

2. 360° LED Neon Flex'in kurulumunun üretici, temsilci veya diğer kalifiye kişiler tarafından yapılması önerilir.

3. Lütfen kurulumdan önce yukarıdaki özellikleri inceleyin.

4. Yukarıdaki veriler standart ürünümüze dayanmaktadır. Küçük bir fark varsa lütfen gerçek ürün verilerinize tabi olun.

5. Yukarıdaki şematik diyagramlar standart ürünümüze aittir. Küçük bir fark varsa lütfen mevcut ürününüze başvurun.

6. LED sürücü watt değeri, güç kaynağı için kullanılan LED Flex Neon'un toplam watt değerinin en az 1,2 katı olmalıdır.

7. Güvenlik için şeritleri doğrudan AC'ye bağlamayın.

8. Herhangi bir asidik veya alkalin madde yasaktır.

9. Bu ürünün veya teknik özelliklerin güncellenmesi durumunda önceden haber verilmez.

10. Unitop yukarıdaki şartnameye ilişkin nihai açıklama hakkını saklı tutar.

Aşağıda 360° LED Neon Flex:'in ana aksesuarları gösterilmektedir

Aksesuarlar
Accessories2
Accessories3

Aksesuarlar hakkında daha fazla ayrıntı istiyorsanız, lütfen Şartname.

Benzersiz aksesuarlara ihtiyacınız olursa lütfen bize bildirmekten çekinmeyin.

Uç kapakları için hangi malzeme seçenekleri mevcuttur?

Aralarından seçim yapabileceğiniz iki malzeme mevcuttur:

1. Silikon Uç Kapağı: Yüksek kaliteli silikondan yapılmıştır, iyi esneklik ve dayanıklılık sunar, neon şeridin ucuna doğrudan takılarak kurulumu kolaydır, yarı şeffaftır ve ışığın kesintisiz olarak geçmesine izin verir.

silicone end cap

2. Metal Uç Kapağı: Isıya dayanıklı metal malzeme, yüksek sıcaklıklı ortamlar için uygundur, vidalı sabitleme gerektirir, silikon uç kapaklarına göre daha güvenli bir kurulum sağlar.

metal end cap

Neon flex'in minimum bükülme yarıçapı ve güvenli şekillendirme yöntemi nedir?

Please maintain a bending diameter over 200mm for the strip’s longevity and reliability. Installation of strips longer than 2 meters should involve teamwork between two people. Avoid twisting, irregular bending, or actions that could scratch the strip during installation, as this can lead to permanent damage.

Installation

360° LED Neon Flex'i kendim kesebilir miyim?

Do not attempt to cut this product. Incorrect cutting can harm the strip, and self-modification voids warranty. For custom lengths, please request in advance, and we will tailor the product to your specifications. We appreciate your understanding and cooperation in maintaining product integrity.

Are there any precautions regarding the power supply?

Are there any precautions regarding the power supply
  1. Use a DC24V isolated constant voltage switching power supply with less than 5% ripple voltage for optimal performance and safety. Using different power supplies may damage the product or create safety hazards.
  2. Maintain a 20% reserve in your power supply’s capacity; it’s advised to use only 80% of its power to ensure stability.
  3. Never connect the power supply while it is live to avoid electric shock. Before wiring, confirm that the power supply voltage matches the product’s voltage requirements.
  4. When using multiple power supplies, avoid connecting the positive poles in parallel. This can lead to system instability and damage the product after prolonged use.

Can LED Neon Flex be used in newly renovated environments?

Testing has shown that substances like formaldehyde and benzene can lead to yellowing in silicone products. This is particularly noticeable when silicone items are used in newly decorated spaces with elements like epoxy floor paint, wall paint, wallpaper adhesive, various decoration materials, or new furniture, which often emit formaldehyde and benzene.

To protect silicone materials from these effects, it’s advisable to either eliminate formaldehyde and benzene from the environment post-decoration before installing the silicone product, or ensure the area is well-ventilated for a certain period before installation.

Özellikler:

360° LED Neon Flex D25 IP65 24VDC

IES Dosyaları:

2400K/2700K/3000K/3500K/4000K/5000K

Spektrum Test Raporları:

2400K/2700K/3000K/3500K/4000K/5000K
